Pitster Pro XTR 250 Enduro Specs
2010 XTR 250 Enduro
CHASSIS AND DIMENSIONS
Color: White
Curb Weight: 248.9lbs
Frame: Chromoly full cradle
Fuel Capacity: 8.60 L
Ground Clearance: 11"
Overall Width: 31"
Seat Height: 36.4" (33" on Lower Link)
Subframe: Removable
Swingarm: CAM Link Suspension w/ Preload, Comp., and rebound adjustable DNM Shock
Wheelbase: 59" Axle to Axle
WHEELS AND TIRES
Front Wheel: 21"
Rear Wheel: 18"
HYRAULIC DISC BRAKES
Front Brake: 250mm Wave Rotor W/ Floating Dual Piston Caliper
Rear Brake: 245mm Wave Rotor W/ Floating Caliper
Rear Pedal: Over the peg CNC
SUSPENSION
Front: SPX inverted forks
Rear: CAM Link Suspension w/ Preload, Comp., and rebound adjustable DNM Shock
Travel: 10" Front/ 10.5"Rear
ENGINE
Bore and Stroke: 70mm x 64.8mm
Clutch: 5 plate wet clutch
Compression Ratio: 10.8:1
Cooling: Liquid cooled
Engine: Four stroke 249.4cc SOHC Water cooled
Gearing: 528/ 14T x 38T
Ignition: Stator/ CDI with lighting coil
Starter: Electric / Kick
Transmission: 5 Speed Manual Clutch
ADDITIONAL FEATURES
Adjustable ride height swingarm : Standard Dual Position Linkage Mounts
Case Saver Chain Deflect Shield: Standard
CNC Alloy Triple Clamps: Standard
Digital Speedo W/ Trip Odometer: Standard
Electric start w/ back up kick start: Standard
Hand Guards: Available
Kick Stand: Standard
Light Kit With Optional Turn Signal and Horn: Standard
Low-Friction Fork Seals: Standard
Motard slider kit (nylon axle, footpeg, and bar end): Standard
Pro Clutch Perch W/ Quick Adjust and Folding Levers: Standard
Rear View Mirrors: Standard
Shifter and brake pedal stay: Standard
Taper Handle Bars 7061: Standard
BUILD-A-BIKE OPTIONS
Clutch and Brake Levers: ASV F:3 Seris folding levers
Custom Graphics: Optional Colors For Your Team, Pre-printed Number Plates and Custom Logo Placement Available
Fork Bleeders: Available
FEATURES NOT FOUND ON OUR COMPETITION
Aggressive All Terrain Tires: Standard
CNC Alloy Hubs With HD 7061 Alloy MX Wheels: Standard
CNC Billet Tripple Clamps: Standard
Floating Disc Brake Calipers With Oversized Rotors: Standard
Gripper seat cover: Standard
Integrated air box: Standard
Nylon chain sliders and chain guide: Standard
Over The Top Rear Brake: Standard CNC model
Oversized Fuel Tank: Standard
Oversized SPX Stainless Steel Footpegs: Standard
Progressive Link Suspension: Standard
Removable quiet core exhaust tip with spark arrestor: Standard
Rim lock : Standard
Shock protection shield: Standard
Stainless Steel Fasteners: Standard
Taper steering bearings w/ dust covers: Standard
Ultra flex plastics: Standard
Upper and lower chain roller wheels: Standard
COMPLETE SPECS
